Product Details

Master rebuild kit for the Ford, Lincoln, and Mercury AOD overdrive automatic transmission.

Covered makes: Ford, Lincoln, Mercury

Year range: 1980-1993

This master rebuild kit contains the following items:

• Transtec overhaul gasket set
• Friction clutch plates
• Overdrive band
• Fluid filter
• Pump bushing
• Extension housing bushing

The Transtec gasket set included in this overhaul banner box kit is the highest quality available. The set includes every rubber seal, paper gasket, O-ring, sealing rings, and metal clad seals that you will need to complete your rebuild. The Transtec gasket sets are considered a premium kit, with the better Duraprene pan gasket, and higher quality gaskets and seals throughout.

Additionally, you can add the following upgrades to this overhaul rebuild kit:

• Steel plates (*pictured)
• Rear reverse band - red lined (*pictured), Kevlar lined, or BorgWarner OEM
• ATSG rebuild manual on CD-ROM
• Transgo Shift Kit - SK-AOD, AOD-HP, Superior Shift Correction Kit - KAOD, KAOD-HP, KAOD-V, Fairbanks - 23001-2
• Sonnax boost valve - 76990K OEM ratio, or 76990-04K HP large ratio
• Superior Overdrive A+ Super Servo – K011
• Reverse servo - 1, 2, or 3 groove
• Reverse servo cover
• Thrust washer kit with Selectives
• Full bushing set
• Intermediate roller clutch – one way sprag
• Planetary overrun roller clutch – one way sprag
• New pump gears
• Intermediate roller clutch spiral snap rings – Sonnax or Superior
• SuperTuff center support snap ring
• TV rod end bushing
• Assembly Grease - Lubegard, Life Smart Blend, or Transjel
• Platinum Lubegard - Insider tip: Many shops use this synthetic supplement in every freshly rebuilt transmission to keep them on the road past the warranty. (Not for Type-F fluid)
• HD torque converter - stock stall speed

Transmission ID: 1980-1993, 4 forward speeds, 14 bolt transmission pan, non-electronic.

This transmission is known by multiple names including AOD, F10D, FIOD, F1OD, and was fitted into the following applications:

Ford:

• Bronco, 14 bolt pan, 1986-1994
• Crown Victoria, 1982-1992
• E150, 14 bolt pan, 1980-1993
• E250, 14 bolt pan, 1980-1993
• F150, 14 bolt pan, 1980-1993
• F250, 14 bolt pan, 1980-1993
• LTD, 1983-1986
• Mustang, 3.8L & 5.0L, 1983-1993
• Thunderbird, 5.0L, 1980-1993

Lincoln:

• Continental, 1980-1987
• Mark VI, 1980-1983
• Mark VII, 1986-1992
• Town Car, 1982-1991

Mercury:

• Capri, 1983-1986
• Cougar, 1980-1993
• Grand Marquis, 1983-1992

This overhaul rebuild box kit fits the following years: 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, and 1993

Remember to soak all of your clutches in transmission fluid for thirty minutes before you install them.
